E.L.B. F-350

Sequence Diagram for Installation/Setting-to-Work (for volume controlled purge Mode1)
Fault: __
For numbers, see Table 1
Switch on mains voltage
Wait for result of self-check
Enter purge volume flow
Value: _____ Liter
Switchpoint MIN pressure
Value: ____ mbar
Switchpoint overpressure
Value: ____ mbar
Enter min. volume flow
Value: _____ l/sec.
Display contrast
Function: ### _____
function of relay K1
Function: _______
Pressure regulation
Function: _______
Parametrization
according to Menu diagram
End of purge time;
observe display
Purge valve closes
Enabling contacts activated
Purge time ended
System is ready
Settings (1)
