E-Mon Class 3200 User Manual

CLASS 3200 METER
62-0390-02 8
3.0 METER TECHNICAL SPECIFICATIONS
Ordering Information: Define brand, class, input voltage, amperage, protocol, and
sensor type in the format A-BB-CCC-DDDD-E-FFF-GGG, where
A = Brand: E for E-Mon
BB = designates Class: 3200 (32), 3400 (34), or 5000 (50) meter
CCC = input voltage: (208, 480, 600, 120 volt for High Voltage)
DDDD = current rating: (100, 200, 400, 800, 1600, 3200, 25HV)
E = enclosure: J = metal (type 1), R = non-metallic (type 4X), M = MMU
FFF= protocol: RTU = Modbus, BAC = BACnet, EZ7 = proprietary
GGG = Sensors: KIT = split-core, SCS = solid-core, “blank” = none supplied
Input Voltage
Configuration
3-wire (delta) Or 4-wire (wye)
Mains Voltage Input Up To 600 VAC RMS available
Input Power 6 VA maximum rating
Current Sensor
Rating
Up To 3200 amps RMS AC available
Power Factor 0.5 leading or lagging
Line Frequency 50-60 Hz
Metering Accuracy ANSI C12.20
Temperature Range -20C to +50C
Relative Humidity
Range
0-95% non-condensing
Altitude 2000 meters maximum
Voltage Overload +25% continuously: +100% For 20 cycles
Current Sensor
Overload
100% for 1 minute
Pollution Degree Degree 2 in accordance with IEC 664
Installation
(Overvoltage)
Category
Category III
Measurement
Category
Category III
M33191
EXAMPLE: E 32- 208 200 J RTU KIT
E-MON
CLASS 3200 METER
INPUT VOLTAGE (208V)
CURRENT RATING (200A)
ENCLOSURE (METAL - TYPE 1)
PROTOCOL (MODBUS)
SENSORS (SPLIT-CORE)

E-Mon Class 3200 Specifications

General

Brand	E-Mon
Model	Class 3200
Category	Measuring Instruments
Language	English
