Digital Processing 145
3. Parametric Equalizer
Parametric EQ allows you adjust the individual parameters of the filter.
Boost and Cut controls “how much” of the signal will be boosted or cut.
Center Frequency sets the center frequency to be boosted or cut, and the
Bandwidth control sets the width of the band to be boosted or cut. The
three parameters are diagrammed below.
The parametric equalizer is a digital (non real-time) equivalent of an
analog equalizer with +12 db of boost and a whopping -48 dB of cut.
Accurate center frequency and bandwidth controls are precise and
exceptionally wide range.
Boost
Cut
Freq.
0 dB
+12 dB
-48 dB
Bandwidth
Frequency
Amplitude
1. Activate Digital Processing module.
2. Select 8. Digital Tools II, 3. Parametric EQ (8/3).
3. If the current sample is stereo, the following screen will appear.
Select the left side, right side, or both sides (stereo), then press
ENTER. Otherwise proceed to the next step.
PARAMETRIC EQ
Side: Stereo
Select L/R/Stereo
4. Select the desired points to be EQ'ed and press ENTER.
EQ secs samples
Start: 0.00 000000
End: 3.13 137873
Size: 3.13 137873
The display will show the current points of the sample to be equalized,
which will be the start and end points of the current sample. Select the
section of sample to be EQ'ed, then press ENTER.
✱
Tip:
The left and right cursor buttons
will change the start and end points so that
they fall on positive zero-crossing points in
the waveform. This will minimize clicks in
the sound when processing only part of a
sample.
