EAE EE-6603BWF - Page 32

Installation, Operation and Parts Manual
EE-6603BWF
32
Pos.
CODE
Name
Specification
Qty
1
Hydraulic power unit
2.2kW/3.0kW/3.5kW
1
2
207103025
Composite washer
G1/4
4
3
310101010
Straight connector
G1/4---G1/4 inside swivel
4
4
624001152
Rubber oil hose
Φ8,L=6000mm
1
5
410210191
Straight connector
6603B-A9-B8
1
6
615021004
Main cylinder of the wheel free lift
6603B-A3-B1
1
7
615019005
Tube connector B
6501-A4-B16
4
8
624001152
Rubber oil hose
Φ8,L=6000mm
1
9
410210181
Three way connector
6603B-A9-B7
2
10
624001155
Rubber oil hose
Φ8,L=2000mm
1
11
615021005
Secondary cylinder of the wheel free lift
6603B-A3-B2
1
12
615021013
Secondary cylinder of the main lift
6603B-A6-B2
1
13
615019006
Straight throttle valve
6501-A4-B15
2
14
624001055
Rubber oil hose
Φ8,L=2000mm
1
15
624001056
Rubber oil hose
Φ8,L=350mm
1
16
615021012
Main cylinde of the main lift
6603B-A6-B1
1
17
624001154
Rubber oil hose
Φ8,L=4500mm
1
18
624001113
Rubber oil hose
Φ8,L=4500mm
1
19
624001153
Rubber oil hose
Φ8,L=6000mm
1
20
624001053B
Rubber oil hose
Φ8,L=6000mm
1
21
624001152
Rubber oil hose
Φ8,L=6000mm
1
Seal rings for cylinders
Seal
rings
CODE
Name
Specification
Qty
Comments
1
207103009
Composite piston seal ring
KGD120*95*22.4*6.35
1
Main cylinder of the main lift
2
207102004
Y seal ring of the piston rod
SD67*77*6
1
Main cylinder of the main lift
3
207105018
Dust proof ring
DH67
1
Main cylinder of the main lift
4
207103010
Composite piston seal ring
KGD100*75*22.4*6.35
1
Secondary cylinder of the main lift
5
207105007
Dust proof ring
DHS50（50*58*6）
1
Secondary cylinder of the main lift
6
207103010
Composite piston seal ring
KGD100*75*22.4*6.35
1
Main cylinder of the wheel free lift
7
207102005
Y seal ring of the piston rod
SD60*70*6
1
Main cylinder of the wheel free lift
8
207105009
Dust proof ring
BHS60
1
Main cylinder of the wheel free lift
9
207103011
Composite piston seal ring
KGD80*60*22.4*6.35
1
Secondary cylinder of the wheel free lift
10
207105008
Dust proof ring
DHS45（45*53*6）
1
Secondary cylinder of the wheel free lift
