EAE EE-6603BWF - Page 37

Installation, Operation and Parts Manual
EE-6603BWF
37
Pos.
CODE
Name
Specification
Qty
7
202101002
Cross socket cap head screw
M3*15
2
8
410210171
Guide track
6603B-A7-B7
4
9
202103024
Cross sunken head bolt
M10*25
8
10
410210161
Cushion head
6603B-A7-B1-C3
8
11
410210151
Cushion holder
6603B-A7-B1-C1
8
12
410211390
Spring
6603B-A7-B1-C2
8
13
203101009
Nut
M16
8
14
208103001
Swivel bolt
M16*120
8
15
614021030
Base plate
6603B-A7-B6
2
16
201102041
Hex head full swivel screw
M16*50
8
17
208106001
Straight oil cup
M8*1
8
18
614021031
Base slot B
6603B-A7-B8
2
19
614021026
Cylinder sheath
6603B-A6-B3
2
20
614021028B
Mechanical safety lock
6603B-A6-B5
2
21
202109014
Inside hex cylinder head screw
M5*45
8
22
310501001
Air cylinder
CQ2B32*20
2
23
615021012
Drive oil cylinder
6603B-A6-B1
1
23
615021013
Assistant oil cylinder
6603B-A6-B2
1
24
410210141
Down shaft of oil cylinder
6603B-A6-B6
2
25
205101055
Bearing
SF-2X 3040
4
26
410210191
Connector B
6603B-A9-B8
2
27
210101005
Hex socket fitting
NPT 1/4
2
28
615019006
Throttle valve
6501-A4-B15
1
29
612021003B
Rotation shaft of the main lift
6603B-A5-B1
4
30
410210121
Pin shaft of the main lift
6603B-A5-B5
2
31
204301012
Circlip
φ35
4
32
205101059
Bearing 3556
SF-2X
4
33
204101012
Class C flat washer
M24
4
34
203103011
Non-metallic lock nut
M24
4
35
204301009
Circlip
D25
4
36
420210070
Down wheel
6603B-A5-B8
4
37
614021029
Base slot A
6603B-A7-B2
2
39
614021024
Arm A (4T)
6603B-A5-B2
2
40
614021025
Arm B (4T)
6603B-A5-B3
2
39
614021050
Arm A (5T)
6603B-A5-B2
2
40
614021051
Arm B (5T)
6603B-A5-B3
2
41
420210060B
Pad block
6603B-A5-B6
4
42
204301009
Circlip
M25(23.2)
4
