designation in the table below.
To configure the Mode switch positions, navigate to the “New Airframe Checklist”, and select the “Set up
Mode/Submode Switches” menu item. Then, select the function of each of the up to 3 Mode switch positions.
Your switch positions may be reversed from the illustration, depending on your radio settings.
The following chart lists the modes that can be programmed for each of the 2 or 3 Mode switch positions (see
section 5.9.1 for a description of these flight modes):
This Mode switch position is not used (unprogrammed)
Selects 2D Flight Mode with no Heading or Altitude Hold
Selects 2D Flight Mode with Altitude Hold, and additionally Heading hold for Fixed
Wing
Selects Loiter Flight Mode (GPS)
Selects Direct Rate 3D Flight Mode (with Attitude Hold)
Selects ’gyro’ stabilization mode
Selects Cartesian Flight Mode
Selects Cartesian Flight Mode with Loiter (GPS)
Selects Polar Flight Mode (GPS)
Selects Polar Flight Mode with Loiter (GPS)
Selects Center Stick Stabilization Flight Mode
Engages RTH test mode (GPS)
Turns off OSD Display. Moving the Mode Switch to a different position will turn the
display back on.
When the Mode switch is in this position, the Submode switch becomes active. See
the Submode section below.
5.10.5 Programming the Optional Submode Switch
To configure the Submode switch positions, navigate to the “New Airframe Checklist” menu, and select the “Set
up Mode/Submode Switches” menu item. Then, select the function of each of the up to 3 Submode switch
positions.
The Submode switch is ONLY active when the Mode switch is set to the “2D + Submod” position.
Your switch positions may be reversed from the illustration, depending on your radio.
