USER GUIDE
94
10 Description of Numeric Readouts
The following numeric readouts can be configured for display. Some require optional hardware.
Voltage of the pack connected to the current sensor
Voltage at the "Vid Tx” power connection of the video harness
Voltage at the "Cam/Mic” power connection of the video harness
Voltage at the Vector’s servo outputs
Temperature of the optional temperature sensor
Approximate air temperature, obtained from the GPS/MAG sensor
Zero referenced altitude, from the onboard pressure sensor
Airspeed from the optional pitot airspeed sensor
RPM reading from the optional RPM sensor
Current flowing through the current sensor
Voltage X Current at the current sensor
Same as RPM reading above
The milliamp hours through the current sensor since bootup
The measured pulsewidth at the Vector’s mode switch input (0% = 1 millisecond,
100% = 2 milliseconds)
The measured pulsewidth at the Vector’s gain knob input, if used
The measured pulsewidth at the Vector’s aileron input
The measured pulsewidth at the Vector’s elevator input
The measured pulsewidth at the Vector’s throttle input
The measured pulsewidth at the Vector’s rudder input
The measured pulsewidth at the Vector’s submode switch input, if used
The measured pulsewidth at the Vector’s kill switch input, if used
The measured pulsewidth at the Vector’s 2
nd
Aileron input, if used
The measured pulsewidth at the Vector’s 2
nd
Elevator input, if used
