Eagle 2000 B - Page 36

- 36 -
6.1 Illustration
Base (continued)
Name Part Numbe
r
Qt
y
1 Turntable FG-01A-19 1
2 Idler Gear FG-01A-18 2
3 Block Limit Switch FG-12A-16 1
4 Ramp Bolt 1
5 Idler Wheel FG-01A-20 24
6 Turntable Gear FG-01A-13 1
7 Limit Switch N1CA2 1
8 Chain 12A 1
9 Base Frame n/a 1
10 Tension Screw 91292A217 1
11 Motor Gear FG-01A-31 1
12 Motor Mount Plate FG-01A-28 1
13 Main Motor CV750-30S 1
14 Cover FG-01A-27 1
15 Motor Fan Cover 1
16 Fan Motor Cover 1
17 Mast Pin 1
