Eagle 2000 B - Page 39

- 39 -
6.3 Illustration
Mast (continued)
Name Part Numbe
r
Qt
y
1 Mast (Post) n/a 1
2 Mast Cover FG-12-02 1
3 Upper & Lower Limit Switch XCKP2145 2
4 Up-Down Motor NMRV040/80-YS6344 1
5 Motor Axis FG-12-06 1
6 Chain 08B 2
7 Slide Rail FG-AL-01 1
8 Up-Down Shelf FG-12-04 1
9 Transition Shelf FG-12-05 1
10 Slide Blocks FG-12-08 4
11 Sprocket FG-12-07 4
12 Sprocket Bracket FG-12-06 1
