- 15 -

6. Main Parts, Components Illustration & Parts List

Description

Part Number

Qty

37

Clamping arm

01-200

1

38

Drag bar

01-197

1

39

Spring

-

1

40

Spring

-

1

41

Knuckle bearing

-

1

42

Pendulum block

01-196

1

43

Edge cam

01-11

1

44

Eccentric shaft

01-35

1

45

Roller wheel

01-36

1

46

Bearing

80100

1

47

Clamping ring

01-38

1

48

Wrench

01-42

1

49

Roller wheel spindle

01-37

1

50

Strapping swing link

-

1

51

Channel steel

-

1

52

Orientation tray

01-68

1

53

Limit board

01-69

1

54

Spindle

01-45

1

55

Adjustment device of strapping force

-

1

56

Sonde bracket

-

1

57

Switch bracket

01-65

1

58

block

-

1

59

Nut

-

1

60

Sleeve

-

1

61

Shaft

-

2

62

Shaft

-

1

63

Shield ring

-

2

64

Bearing

-

1

65

Bearing

-

1

66

Bearing

-

1

67

Shaft

-

1

68

Bearing

-

1

69

Motor

-

1

70

Belt wheel

-

1

71

Belt

-

1

72

Orientation board

-

1
