Eagle 800 - Top Body Assembly

- 17 -
6. Main Parts, Components Illustration & Parts List
6.3 Top Body Assembly
Description
Part Number
Qty
1
Front plate
01-90
1
2
Left top knife combination
-
1
3
Middle top knife combination
-
1
4
Right partition board
01-93
1
5
Left partition board
01-92
2
6
Post
01-95
2
7
Tension spring
01-97
3
8
Post
01-96
1
9
Back plate
01-91
1
10
Baffle plate
01-94
1
11
Right top knife combination
-
1
