EI-1000 & 2000: Setup, Calibration and Troubleshooting.
Page 3 of 19
Table of Contents:
Page:
3
4 Installation and Wiring.
5 Calibration.
6 Operation in automatic modes.
7 Scale Wiring color codes.
8 Troubleshooting.
9
10
11 Changing Configuration Parameters, turning off auto-zeroing.
12 4-20 mA Outputs - Parameter Setup, Testing, and Calibration.
13 4-20 mA Troubleshooting.
14
15 Day tank use - Instrument setup.
16 Calibrating an Empty Day Tank.
17 Calibrating a Day Tank that can’t be emptied.
18
19 Your notes.
The “Setup, Calibration, and Troubleshooting” manual shipped with new
instruments will have the Operation manual attached. It contains more in-depth
information such as parameter explanations, set-point settings, diagnostic
modes, and serial communications (standard RS-232, RS-485, & MODBUS
available).
If you need a copies of this or any manual contact:
Eagle Microsystems at 610-323-2250.
Email: info@eaglemicrosystems.com
www.eaglemicrosystems.com
