EI-1000 & 2000: Setup, Calibration and Troubleshooting.
Page 6 of 19
Operation in automatic modes 3 and 4:
1. Zeroing: Starting with an empty scale showing the gross weight, press the
zero button if the reading is not zero.
If the scale shows “n0 0” the weight exceeds the push to zero percentage
(parameter P114). See the calibration section to zero the reading.
If nothing happens double check that the GROSS light is lit. Use the select
button to show the gross weight if needed. Press zero again. You may not
be in mode 3 or 4 if the instrument still won’t zero. See the calibration
section to zero the reading.
2. Place tank on scale. Check that the gross weight is correct. (Gross = Tare +
product in tank). You may have to wait a few minutes for a stable reading while
the contents of the tank to settle.
3. If the gross weight is not correct and the GROSS light it flashing, use the
UP/DOWN arrows to adjust the weight.
If the GROSS light is not flashing, hold down the select button a few
seconds until it does.
4. Press select.
Instrument will show the tare weight in operation mode is 4. Go to step 5.
Instrument will show the correct remaining weight if the operation mode is
3. You’re done! (Partial tank see below.)
5. Use the UP/DOWN arrows to set the correct tare weight if needed.
6. Press select to save the tare and show the remaining weight.
Partial tank notes:
Assume the gross weight is correct in steps 2 and 3. If using mode, 4 continue
normally. The remaining weight will be correct.
Mode 3 will show a full tank in step 4. To fix: hold down the UP arrow while the
remaining weight is shown. The reading will jump to TARE after several seconds.
Use the UP/DOWN arrows to set the tare weight. Press SELECT when done.
Please copy this page and post it by the EI-1000 / 2000 for quick reference.
