73
Digital Data/Chart
This mode shows the chart on the right side of the screen. The left side has
six large digital boxes or windows containing: Water Depth; Water Speed
(from an optional speed sensor); Water Distance (distance traveled or log, it
also requires a speed sensor); Surface Water Temperature; Temperature #2
and Voltage used. (Note: Temperature #2 requires an additional optional
temperature sensor.)
Digital Data/Chart
Customizing the Digital Data/Chart Screen
The Digital Data/Chart screen can be customized to show digital data
different from the defaults first shown. To customize this screen:
1. From the Sonar Page (in Digital Data mode), press
MENU
|↓ to
C
USTOMIZE
|
ENT
.
2. The W Speed window title bar flashes, indicating the window con-
tents can be changed. Press
ENT
|↑ or ↓ to select data type|
ENT
|
EXIT
.
Options List for customizing Digital Data windows. At left, the list first
appears with Water Speed selected. At right, Temperature 3 has been
picked to replace Water Speed in the top digital data window.
