On board blocking relay (40A)
Black
Black
30 - Common
87 - Normal closed
H1 20-PIN
CONNECTOR
Dual-stage/zone
Shock Sensor
Plug-in dual stage
shock sensor
R.F Antenna
Antenna
Extend the whole wire, align it
with the intersection of dashboard
and the front window glass.
Keep it away from the metal at
least 5 centimeter to have the
best receiving condition.
Blue LED
indicator
Blue LED
indicator
Call switch
WIRING DIAGRAM
To Next Page
