3 spray patterns
By slightly loosening the Air Cap Ring (at the front) you can turn the Air Cap a little (catch
locking system) and obtain 3 different spray patterns: (Fig. 5)
Horizontal and Vertical Spray
Vertical and Horizontal for normal sized jobs
Round Spray
Round for small and precise jobs
The most commonly used technique for painting a wall is the ‘crisscross’ technique, i.e. you apply
the product in horizontal lines and then cross over these lines by applying the produ
ct in
vertical lines; (Fig. 6)
1) Adjust the Air Cap to obtain a Vertical spray, then pull the Trigger and move your arm across to
the right.
2) When you get to the end of the line, release the Trigger for a moment and then apply the
product in the opposite direction just beneath the line you have sprayed.
3) Proceed in this manner applying the product in Horizontal lines one underneath the other.
4) Next, adjust the Air Cap to obtain a Horizontal spray and apply the product in horizontal lines
over the lines you have just sprayed.
Release the trigger to avoid overspraying which will cause the product to run.
Cross over the horizontal lines (spayed with a Vertical pattern) with vertical lines (sprayed with a
Horizontal pattern). Only the fore arm must move not the wrist.
Important Information
This Spray Pack should only be used with the following Earlex HVLP unit, Spray Station 5900.
Using with another HVLP unit may affect the Spray Pack’s performance. This does not affect your
statutory rights.
THIS PRODUCT IS NOT SUITABLE FOR USE WITH SPRAY GUN MODEL L0150
Your Spray Pack is supplied with the following: Fig 2.
4
No Description Part No
23. Spray Pack L0885
24. Lid L0223
25. Seal L0682
26. Strap Assembly L0493
9527. Short Tube 1.2m L08
28. Hose Clips L0631
29. Hook and Loop 180mm x5 L0905
30. Long Tube 4m L0894
