EAT C-Sharp User Manual

15
Step 3:
Anti-skating sliding mechanism is supplied with mounted anti-skating weight and also with
anti-skating thread. Put the eye of the anti-skating thread onto the hole for HOOK SCREW
and screw the HOOK SCREW into the tonearm as is mentioned on the picture below.
Step 4:
Put the anti-skating mechanism to the end of anti-skating support rod. Anti-skating thread
should fit into the groove in the tonearm.
Be careful, there is a danger to rip off thread by tensile force.
!

EAT C-Sharp Specifications

General

Drive Principle	belt drive
Speed variance	±0.1%
Effective arm length	230 mm
Power consumption	5 W
Speeds	33, 45 RPM
Signal to Noise	70 dB
Output	RCA
