EAT C-Sharp User Manual

14
g) Anti-skating assembly and adjustment
Anti-skating mechanism is supplied partially disassembled to avoid damage during transport.
For exact installation please follow next steps described below.
Step 1:
Prepare all parts supplied from the accessories bag.
Anti-skating sliding mechanism with anti-skating weight and thread for mounting on the
tonearm and anti-skating support rod.
Step 2:
Put the anti-skating support rod in the middle of the shaft which is rigidly mounted on the
tonearm as is mentioned on the picture below. Then tighten the screw to prevent
movement on the shaft.

EAT C-Sharp Specifications

General

Drive Principle	belt drive
Speed variance	±0.1%
Effective arm length	230 mm
Power consumption	5 W
Speeds	33, 45 RPM
Signal to Noise	70 dB
Output	RCA
