a) Cartridge assembly

Install the cartridge into the aluminium headshell. Install screws that are part of the

cartridge box into the oval holes of the headshell and fix it into the cartridge holes from the

bottom side of the aluminium headshell.

Connect the cartridge as mentioned below:

• White left channel L+

• Red right channel R+

• Green right channel R-

• Blue left channel L-

For correct position of the cartridge, use the two point cartridge alignment protractor which

you find in the accessories.

b) Counterweight assembly

Supplied counterweight has special TPE (termo plastic elastomer) damping. This

counterweight has two separate parts.

First part is counterweight itself and second part is additional insert which allows to balance

heavier cartridges.
