EAT C-Sharp User Manual

16
Step 5:
Anti-skating force adjustment:
Anti-skating downforce must be adjusted corresponding to the downforce as follows:
Downforce: Anti-skating groove:
Lower than 13mN 1
st
from bearing rings
13 - 18 mN 2
nd
from bearing rings
18 - 25mN 3
rd
from bearing ring
5. Turntable level position
On the turntable are mounted three precision adjustable damped feets for perfect setting of
the turntable plane. Put the spirit level on the carbon top plate balance the turntable by
screwing / unscrewing the feets . Check the plane from several perspectives.

EAT C-Sharp Specifications

General

Drive Principle	belt drive
Speed variance	±0.1%
Effective arm length	230 mm
Power consumption	5 W
Speeds	33, 45 RPM
Signal to Noise	70 dB
Output	RCA
