Eaton.com/bussmannseries 7
12.05
(306.1)
5.24
(133.1)
0.78
(19.8)
2.00
(50.8)
5.76
(146.3)
6.69
(169.9)
0.40
(10.2)
7.47
(189.7)
Ø0.20
(Ø5.1)
10.48
(266.2)
0.67
(17.0)
5.47
(138.9)
1.00
(25.4)
11.25
(285.8)
Figure 3. 300-400kA units in a NEMA 1 enclosure,
weight = 13.5 lbs (6.1 kg)
BSPD SPDs for switchgear and power distribution panels Instruction Sheet IS10207 Rev 3
Effective July 2015
Figure 5. form C contact relay wire color codes
Figure 6. 3-phase, delta units
Figure 7. 3-phase, Wye units
BLUE / WHITE
RED / WHITE
ORANGE / WHITE
COMMON
NORMALLY OPEN
NORMALLY CLOSED
Figure 4. 120-400kA units in a NEMA 4X enclosure,
weight = 120-200kA; 14.6 lbs (6.6 kg),
250-400kA; 21.0 lbs (9.5 kg)
A B
120-200kA 2.60 (66.0) 5.39 (137.0)
250-400kA 4.10 (104.1) 7.68 (195.0)
