Eaton DF6000 - Expected Voltage Readings

73 Amended: Jan 2014
Test
Test
DF 6000 Motherboard (.ypcb2153)
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
Aux
Relay
Fault
Relay
24v
0/p
Fire
P/E
Fire
R/E
Loop 1 Loop 2 Loop 3 Loop 4
Class
CX
Sounder 1& 2 Sounder 3 & 4
+ 26v
0v
+ 26vRaw
0v
+ 5v
Printer
Connector to PSU
Voltages measured at main contacts with mains and battery connected.
• Aux Relay : Dry contacts NO/C/NC
• Fault Relay Output : 13.6v no fault 0v when in fault
• 28v Output : 28.5v approx with no load
• Fire P/E & R/E : -0.6v no fire +28v when in fire
• Loops 1-4 : 0v unused, +22v normal, +24v in fire, +27v during autolearn.
• Sounder 1-4 : -0.6v monitor, +28v when in fire.
Voltages measured at vertical red connector with mains and battery connected.
• +26v to 0v : reads approx +27.8v
• +26v Raw to 0v : reads approx +28.15v
• +5v Printer to 0v : reads approx +5.5v
Voltages measured across battery leads using 6K resistor as load, mains
connected.
• Factory set to give +27.5v
