- 1 -
Thank you for choosing this Eaton Logic Controller (ELC) series has
controllers with 10 to 40 embedded I/O points. To ensure proper installation,
operation and maintenance, please read this instruction sheet carefully
before installing ELCB-PB.
This instruction sheet provides only information on the electrical
specification, general functions, installation and wiring. It should be read
and understood before attempting to install or use the unit.
Further information can be found in the ELC series Programming
Manual.
These are OPEN TYPE controllers and therefore should be installed in
an enclosure free of airborne dust, humidity, electric shock and vibration.
Your application may require that the enclosure be locked to prevent
non-maintenance staff from operating the controller (e.g. key or specific
tools that are required for opening the enclosure) in cases where danger
and damage to equipment or personnel may occur.
DO NOT connect AC power to any of the DC I/O terminals; serious
damage may occur. Check all wiring before switching on power.
Ensure that the ground terminal is correctly grounded in order to
prevent electromagnetic interference.
This manual is subject to change without notice.
Product Profile
+2 4V
24 G S/ S
X0
X1 X2
X3
X4
X5 X6
X7
L
N
C0 Y0
Y1 Y2
Y3 C1
Y4
Y5
Panel mounting
hole
I/O terminal
numbers
DC sensor
power supply
output
I/O point
indicators
COM1 Comm.
(RS-232C)port
DIN rail mounting
slot (35mm)
Panel mounting
hole
I/O terminals
DIN rail clip
POWER, RUN & ERROR
indicators
I/O terminal
numbers
AC power
supply input
COM2 Comm.
(RS-485)port
D+
D-
SG
Y6
Y7
Module name
CO M2
CO M1
X1 0
X11 X12
Note1: The above figure is the layout of ELCB-PB20NNDR.
Dimension
To Next Page
