Eaton i-on40H Engineering Guide

Introduction
Page 2
 On-board outputs and wired zones (depending on the control unit).
 On-board connections for a wired siren/strobe unit.
 On-board connections for an external loudspeaker.
Table 1: Overview of features
Feature
i-on30R
i-on40H
EN 50131 security grade
2
2
Zones
Max on-board radio zones
30
30
Max on-board wired zones (Note 6)
0
10
Max zones on expanders, keypads, etc.
30
40
Max wired and radio zones (system wide)
60
80
Bus
RS485 Buses
1
1
Max bus devices
20
20
Outputs
Max on-board radio outputs
10
10
On-board transistor outputs
1
1
On-board relay outputs
0
2
Max outputs on expanders, keypads, etc.
30
40
On-board plug-by outputs
0
12
On-board siren\strobe connections
Yes
Yes
Max custom outputs
4
4
Max outputs (system wide) (Note 5)
30
40
Ports
Ethernet port
Yes
Yes
USB port
Yes
Yes
On-board loudspeaker connections
1
1
Micro SD card slot
Yes
Yes
Devices
Max wired keypads and 2-way radio keypads (Note 2)
20
20
Max 1-way radio keypads (Note 3)
4
4
Max external radio siren\strobe units (Note 4)
4
4
Max internal radio sounders (Note 4)
4
4
Max Wireless Access Modules
4
4
Case
Control unit case
Plastic
Plastic
Batteries
1 (7Ah)
1 (7Ah)
Power supply
1.0A
1.0A
Combined back/lid tamper
Yes
Yes
Software
Users
30
50
Part sets (in part set mode)
3
3
Max partitions (see Note 1)
4
4
Mandatory log events
750
750
Non-mandatory log events
250
250
Calendar set events
10
10
Calendar set exceptions
30
30
Max shunt groups
4
4
Max simultaneous keypad sessions
4
4
Web browser interface
Yes
Yes
Auto remote diagnostics (UK only)
Yes
Yes
