Matrix Telecom Inverter System
Installation and Operation Guide
Issue:
IPN 997-00012-68D
Issue Date:
February 2010
Eaton Corporation
Telecommunications Power Solutions
www.eaton.com/telecompower
DCinfo@eaton.com

Table of Contents

Questions and Answers

  • S
    samuelcantrellAug 18, 2025
    What to do if my Eaton Inverter has no AC output and all LEDs are off?
    • B
      brandongardnerAug 18, 2025
      First, check if all input cables are firmly connected to the power source and that the power source is switched on and has sufficient power. Also, verify that all inserted inverter modules are the same model.
  • E
    Emily RuizAug 20, 2025
    Why is the red LED on my Eaton Inverter on and there is no AC output?
    • W
      William BradleyAug 21, 2025
      The red LED and lack of AC output could indicate several issues. Check that the input wiring has correct polarity (positive to positive, negative to negative). Ensure the output voltage is within the operating range of your connected device. Also, verify that the inverter output is not shorted by turning off the input power source to remove any short circuits. Finally, negative power protection could be the cause. For multi-shelf systems, remove any jumper on the JP2 connector. For single-shelf systems, ensure there is a jumper on the JP2 connector.
  • K
    Kathy GreenAug 23, 2025
    What to do if my Eaton INV-STS-050 has no AC output and both yellow and red LEDs are on?
    • S
      Susan CookAug 23, 2025
      This usually means the load exceeds 125% of the inverter's capacity. Reduce the load to below 100% of the total power rating.
  • D
    Debra SteeleAug 26, 2025
    What does it mean if the red LED is flashing fast on my Eaton INV-STS-050 Inverter?
    • M
      Monica BurtonAug 26, 2025
      A rapidly flashing red LED can indicate that the inverter failed to soft start or that the inverter temperature is above the limit. Try rebooting the inverter system by switching the input power source off and on. If that doesn't work, let the inverter idle to cool down for a few minutes.
  • B
    Brian TateAug 28, 2025
    What does it mean if the yellow LED is on while AC output exists on my Eaton Inverter?
    • P
      Patricia McclainAug 28, 2025
      If the yellow LED is illuminated while AC output is present, it signifies that the load is over 100% but below 125% of its total power rating. Reduce the load to below 100%.
  • C
    Charles MoranAug 30, 2025
    Why is the yellow LED flashing on my Eaton INV-STS-050 Inverter when AC output exists?
    • D
      Dylan HodgeAug 30, 2025
      A flashing yellow LED during AC output suggests that the input voltage is outside the operating range. Make sure the input voltage is between 45V and 58V, and check the connection to the battery or DC source.
  • C
    Craig WeberSep 2, 2025
    What does it mean when the Eaton INV-STS-050 continuously delivers power, but the red LED is flashing slowly?
    • W
      weavermarieSep 2, 2025
      A slowly flashing red LED while the inverter is delivering power can point to an EEPROM failure or a fan failure. Try rebooting the inverter system by switching the input power source off and on. If the fan is blocked, clear the obstruction. If the fan is not working, the inverter may require servicing.
  • V
    Vanessa MorganSep 4, 2025
    How to troubleshoot an Eaton Inverter module that cannot be properly inserted?
    • J
      James FergusonSep 5, 2025
      Ensure that you are not trying to insert an STS module into the inverter shelf, as the inverter shelf only holds inverter modules. Also, verify that the inverter module is the correct model. All inverters must be the same model.
  • R
    Raymond AdamsSep 7, 2025
    What does it mean if the yellow LED is on and there is no AC output from my Eaton Inverter?
    • R
      Roger ArnoldSep 7, 2025
      The absence of AC output with a lit yellow LED indicates that both the inverter and the utility AC source are in an abnormal state. Check both the AC mains and the inverter output.
  • G
    Gregory PerezSep 9, 2025
    What does it mean if the green LED is on and the red LED flashes at 1Hz on my Eaton Inverter, while the AC output is normal?
    • K
      Kelsey ClarkSep 9, 2025
      This indicates an EEPROM fault, meaning the EEPROM cannot correctly write or read data, or a CAN communication error. Check the connection of CAN signal cables. The EEPROM fault will not influence the STS AC output and the alert will turn off automatically after 10 seconds.

Summary

Preparation

Battery Precautions

Safety instructions for handling, charging, and disposing of batteries.

Wiring Requirements

Requirements and standards for electrical wiring connections.

Installation

Wiring Connection

Detailed instructions for connecting the system's wiring.

Task 4 - Single-Shelf Wiring Option

Specific wiring procedures for systems configured with a single shelf.

Task 5 - Multi-Shelf Wiring Option

Specific wiring procedures for systems configured with multiple shelves.

Task 6 - Connect Controller (if used)

Steps for connecting the controller module to the system.

Task 7 - Connect STS (if used)

Steps for connecting the Static Transfer Switch (STS) module.

Task 8 - Connect MBS (if used)

Steps for connecting the Maintenance Bypass Switch (MBS) module.

Module Installation and Removal

Procedures for installing and removing various system modules.

Task 10 - Install STS and Inverter Modules

Step-by-step guide to install STS and inverter modules into shelves.

Task 11 - Install Controller and Interface Modules

Steps for installing controller and interface modules into chassis.

Operation

Pre-Operation Check

Essential checks to perform before powering up the system.

Apply Power

Procedure for safely applying power to the inverter system.

Status Monitoring

How to monitor the system's operational status via the controller.

Parameter Setting

Instructions for setting and configuring system parameters.

Parameter Programming

Detailed guide on programming specific inverter parameters.

Alarm Settings

Configuration options for system alarms and notifications.

Maintenance

Troubleshooting

Guides for diagnosing and resolving system operational issues.

Inverter Troubleshooting

Specific troubleshooting steps for inverter modules.

Specifications

STS;MBS Operation

Operation of STS at each MBS position

Details how the STS module operates in conjunction with MBS switch positions.
