Table 1 Programmable Features and Set points
Following is a description of each programmable set
poi
nt.
Please Enter Password - If the
password is enabled,
the user will be prompted to enter the password at this
time. If there are no buttons pressed for five (5) seconds,
the controller will switch back to the automatic mode.
Language - Three (3) languages are offered as
standard. They are English, French, or Spanish. A fourth
language can be added utilizing the USB port. Consult
Eaton for available languages. Refer to Appendix B for
programming.
Regional Settings - Re
fer to Appendix C. Following are
the descriptions of each menu item:
Change Da
te - Factory set, however, this parameter
allows the user to set the current date.
Change Time - Factory set to Mountain Standard
Time (MST). This menu item allows the user to
adjust the time to the local time. The clock is of the
24-hour type.
Description Factory Default Range
Main Program - (Appendix A)
Language (Appendix B) English English/French/Spanish
Regional Settings - Appendix C
Change Date Current Date Unlimited
Change Time Current Time (MST) 24 Hours
Pressure Settings - Appendix D
Pressure Sensor Enabled Enabled/Disabled
Drain Valve Enabled Enabled/Disabled
Pressure Start Point 100 PSI 0-500 PSI
Pressure Stop Point 110 PSI 0-500 PSI
Low Pressure Alarm Point 105 PSI 0-500 PSI
High Pressure Alarm Point 300 PSI 0-500PSI
Auto Shutdown Automatic Enabled/Disabled
Proof Pressure Switch Disabled Enabled/Disabled (Foam Only)
Low Suction Shutdown (Foam Level) Disabled Disabled/Enabled
Pressure Deviation 10 PSI 1-50 PSI
Hourly Pressure Recording Disabled Enabled/Disabled
Timer Values - Appendix E
Run Period Timer 10 Minutes 0-45 Minutes
RPT Start Mode Pump Run Pump Run/Pressure Stop Point
Acceleration Timer 2 Seconds 0-10 Seconds
Weekly Test Timer Disabled 7 Days/24 Hours (0-60 Minutes)
Fail To Start 20 Seconds 0-60 Seconds
Fail To Stop 3 Seconds 0-60 Seconds
Sequential Start Timer Disabled Disabled / 1-300 Seconds
Alarm Set Points - Appendix F
Phase Rotation ABC ABC/CBA
Phase Failure Setup 80% +20-80%
Overvoltage +10% +5-30% / Disabled
Undervoltage -10% -5-30% / Disabled
Over Frequency +5% +3-10% / Disabled
Under Frequency -5% -3-10% / Disabled
Audible Common Alarm Disabled Enabled/Disabled
Custom Input/Output - Appendix G
Custom Inputs #1-9 Undefined Refer to Appendix G(a)
Custom Outputs #1-9 Undefined Refer to Appendix G(b)
Custom Lights #1-2 Undefined Refer to Appendix G(c)
Main Menu Password (Appendix H) Disabled Enabled/Disabled - Any number of four (4) button
combinations from keypad
