34008030EN/AD - Page 13
2. Installation
2.3 Installation in tower position
Follow steps 1 to 3 to adjust the tower stands for the upright position.
Always keep 150 mm free space behind the UPS rear panel.
The distance between the tower stands should be 450 mm.
