Eaton MX 4000 RT - Rack Position; Standard Positions; Tower Position

34008030EN/AD - Page 7
1. Presentation
1.1 Standard positions
Tower position
Rack position
Dimensions (H x W x D) in mm / Inches
MX 4000 RT 444.5 x 131 x 700 /
17.5 x 5.16 x 27.56
MX 5000 RT 444.5 x 131 x 700 /
17.5 x 5.16 x 27.56
MX EXB RT 444.5 x 131 x 650 /
17.5 x 5.16 x 25.6
Weights in kg / lbs
MX 4000 RT 57 / 125
MX 5000 RT 57 / 125
MX EXB RT 70 / 154
Dimensions (H x W x D) in mm / Inches
MX 4000 RT 131 x 444.5 x 700 /
5.16 x 17.5 x 27.56
MX 5000 RT 131 x 444.5 x 700 /
5.16 x 17.5 x 27.56
MX EXB RT 131 x 444.5 x 650 /
5.16 x 17.5 x 25.6
Weights in kg / lbs
MX 4000 RT 57 / 125
MX 5000 RT 57 / 125
MX EXB RT 70 / 154
