1. Presentation
ModularEasy
MX ModularEasy enables parallel
operation when combining two MX UPSs.
Consequently you can enhance the
availbility level of your equipment (N+1
redundancy). You can also double your
secured power capacity according to your
needs (migration, network extension...).
In the unlikely event a major fault would
occur, the manual maintenance bypass of
MX ModularEasy would allow the UPS
maintenance without interrupting your
connected equipment.
In single unit mode, MX ModularEasy
combined with one MX UPS adds a
second level of availability to your
installation.
The manual bypass mode allows the
replacement of the UPS without any
interruption to the connected equipment
in case of a major fault that would not be
related to the most critical components of
the UPS (i-e front-accessible, hot-
swappable Battery and Power Sub-
Modules).
Example of MX ModularEasy connected with two UPSs in parallel operation
UPS 1
(MX RT)
MX RT ModularEasy
UPS 2
(MX RT)
UPS output to load
AC Normal input
