Power Xpert Insight Gateway
Quick Start Guide
3
Mounting
The PXG900 can be panel-mounted vertically or horizontally, and fastens via four user-supplied screws on the rear plate. It can also be
attached via a DIN rail (the adapter is shipped with the gateway, along with appropriate mounting machine screws).
You can adjust the DIN rail adapter to allow vertical or horizontal mounting (default) by removing the two Phillips screws to the left
and right of the center pivot bolt and rotating the DIN mounting clip.
