FIELD INSTALLED UPM INSTALLATION PLAN AND UNPACKING
EATON 9395 Field Installed UPM Mechanical Installation Manual S 164201717 Rev 3 www.eaton.com/powerquality
3−4
Front
758.8
[20]
37
[1.5]
475.4
[18.7]
34
[1.4]
Dimensions are in millimeters [inches].
Figure 3-3. FI−UPM Cabinet Dimensions (Top View)
Front
602.8
[23.7]
213
[8.4]
Dimensions are in millimeters [inches].
Figure 3-4. FI−UPM Cabinet Dimensions (Bottom View)
Front
12.7 [0.5] X 15.8 [0.62] Slot (6X)
830
[32.7]
346
[13.6]
346
[13.6]
69
[2.7]
39.2
[1.54]
59.2
[2.4]
848
[33.4]
730
[28.7]
808
[31.8]
Dimensions are in millimeters [inches].
Figure 3-5. FI−UPM Cabinet Dimensions (Bottom View with Mounting Brackets)
