Eaton S611 Quick Start Installation Guide

Installation
S611 Soft Starter MN03901003E—January 2012 www.eaton.com 3
Mounting Hole Dimensions
Approximate Dimensions in mm [Inches]
Frames A through D Frames E and F
70.0
[2.76]
464.7
[18.30]
110.0
[4.33]
10.0
[0.39]
Ø
70.0
[2.76]
80.0
[3.15]
90.0
[3.54]
80.0
[3.15]
155.0
[6.10]
562.0
[22.13]
10.0
[0.39]
Ø
127,0
[5.00]
127,0
[5.00]
155.0
[6.10]
127,0
[5.00]
127,0
[5.00]
