50/75/150 VCP-W
Selectable Ground and Test Device
Figure 3.3.b. Rear External View of 150 VCP-W SG&T Device
Back External View (150 VCP-W SG&T Shown)
1 Lifting Point 2 Primary Disconnects (1200A / 2000A Shown)
2
1
1
