4
Instruction Book IB182312EN June 2016 www.eaton.com
50/75/150 VCP-W
Selectable Ground and Test Device
SECTION 1: INTRODUCTION
The purpose of this book is to provide instructions for receiving and
handling, storage, installation, operation and maintenance of 150
VCP-W Selectable Ground and Test Devices. This selectable ground
and test device is designed to be used in existing Westinghouse,
Cutler-Hammer, or Eaton Type VCP-W metal-clad switchgear.
Type VCP-W selectable ground and test devices are designed for
insertion into the breaker compartment to gain access to the primary
stationary contacts. It provides convenient means to:
1. Ground a circuit for maintenance work;
2. Apply potential for testing; and/or,
3. Access both bus and line circuits for “phasing out” tests.
4. Depending on customer specification, key interlocks may be
deleted. Line/Load and Phase labeling may be optionally provided.
CAUTION
BECAUSE OF THE UNIQUE APPLICATION AND VAST VARIETY OF SYSTEM /
USER REQUIREMENTS, SPECIFIC SAFE OPERATING PROCEDURES FOR THE
USE OF THIS DEVICE MUST BE DEVELOPED BY THE USER.
WARNING
SATISFACTORY PERFORMANCE OF SELECTABLE GROUND AND TEST
DEVICES IS CONTINGENT UPON PROPER APPLICATION, CORRECT
INSTALLATION AND ADEQUATE MAINTENANCE. THIS INSTRUCTION
BOOK MUST BE CAREFULLY READ AND FOLLOWED IN ORDER TO OBTAIN
OPTIMUM PERFORMANCE FOR LONG USEFUL LIFE OF THE SELECTABLE
GROUND AND TEST DEVICES.
THESE SELECTABLE GROUND AND TEST DEVICES ARE PERSONNEL
PROTECTIVE DEVICES, AS SUCH, THEY ARE MAXIMUM RATED DEVICES.
THEREFORE, THEY SHOULD NOT UNDER ANY CIRCUMSTANCES BE
APPLIED OUTSIDE THEIR NAMEPLATE RATINGS.
1.1 AVAILABLE 150 VCP-W SELECTABLE GROUND AND
TEST DEVICES
Refer to Table 1.
Table 1. 150 VCP-W Selectable Ground and Test Device Availability and Interchangeability
Nominal Voltage Class
(kV)
Existing Breaker MVA
Ratings
Sized For Circuit
Breaker Compartment
(Amps)
Rated Short-Time Current
kA / RMS
Symmetrical
Rated Momentary Current
kA / Peak
BIL Capability
(kV)
5 36 / 49 1200 / 2000 / 3000 50 97 / 132 60
7.5 41 1200 / 2000 / 3000 50 111 95
15 23 / 41 / 50 1200 / 2000 / 3000 50 62 / 109 / 130 95
