45
Figure 27b. DG5S-8-** (K/R/S)-10 or DG5S-H8-**(K/R/S)-20 Internal Pressure Passages & Plug Locations
B
P
A
T
“X” Port
Plug Installation Table
Model
“C”
Plug
“B”
Plug
“A”
Plug
DG5S-8-**-KRS10
DG5S-8-**-E-KRS-10
DG5S-8-**-X-KRS-10
DG5S-8-**-X-E-KRS-10
*In
In
Out
In
Out
*In
* - Denotes Orifice Plug
Does
not
Exist
Out
“C” Plug
Check Valve
“A” Plug
Figure 27c. DG5S8-**-10 or DG5S-H8-**-20 Internal Drain Passages & Plug Locations
B
P
A
T
“Y” Port
“T” Plug (Remove for
Internal Drain Models)
DG5S8-10 (with or w/o check valve) or
DG5SH8-20 (with or w/o check valve)
Internal Drain Passages & Plug Locations
