EBARA CDX 70 - Packing Dimensions and Weight

CENTRIFUGAL PUMPS CDX
DIMENSIONS AND WEIGHT 60Hz
401
EBARA PUMPS EUROPE S.p.A.
Rev. E
PACKING
[1~] [3 ~] [ 1~] [ 3~] [1~] [3~] [1~] [ 3~]
CDXM 70/076 CDX 70/ 07 6 215 2 15 2 65 26 5 33 2 3 32 9.1 9
CDXM 70/106 CDX 70/ 10 6 215 2 15 2 65 26 5 33 2 3 32 1 0.2 1 0. 3
CDXM 70/156 CDX 70/ 15 6 215 2 39 2 65 28 9 33 2 3 72 1 2.4 1 3. 1
CDXM 120/106 CDX 120/106 215 215 265 265 332 332 10.3 10.3
CDXM 120/156 CDX 120/156 215 239 265 289 332 372 12.3 13
CDXM 120/206 CDX 120/206 239 239 289 289 372 372 16 15.2
CDXM 200/156 CDX 200/156 215 215 265 265 332 332 11.6 11.3
CDXM 200/206 CDX 200/206 239 239 289 289 372 372 15.7 16.4
- CDX 200/ 30 6 - 2 39 - 28 9 - 3 72 - 1 7. 6
Type pumps Packing [mm] Weight
XY Z[kgf]
Single Phase Three Phase
[1~] Single phase
[3~] Three phase
