CENTRIFUGAL PUMPS CDX
SELECTION CHART 60Hz
201
EBARA PUMPS EUROPE S.p.A.
Rev. E
l/min 0 20 50 80 90 120 140 160 180 220 250
m³/h 0 1.2 3 4. 8 5.4 7. 2 8.4 9.6 10.8 13.2 15
CDXM 70/076 CDX 70/076 0.55 0.75 23.5 22.2 20 17.5 16.5 - - - - - -
CDXM 70/106 CDX 70/106 0.75 1 32.3 31 28.6 26 - - - - - - -
CDXM 70/156 CDX 7 0/156 1.1 1.5 44.5 43.5 40.2 36.3 - - - - - - -
CDXM 120 /1 06 CDX 12 0/1 06 0 .75 1 23 .8 - 21 .8 20. 2 19.7 18 .1 16.8 15 .5 14 - -
CDXM 120 /1 56 CDX 12 0/1 56 1.1 1.5 32 - 29 .8 28. 3 2 7.7 26 .2 25 23.5 - - -
CDXM 120 /2 06 CDX 12 0/2 06 1.5 2 45 .5 - 43 .2 41 40.4 38 .2 3 6.8 35 .5 - - -
CDXM 200 /1 56 CDX 20 0/1 56 1.1 1.5 23 .3 - - 20. 8 2 0.4 19 .4 1 8.6 17 .8 17 1 5.2 13 .5
CDXM 200 /2 06 CDX 20 0/2 06 1.5 2 32 - - 30 2 9.5 28 .6 2 7.9 27 .2 26. 3 2 4.6 2 3
- CDX 200/3 06 2.2 3 38 .8 - - 35. 5 3 5.1 34 3 3.3 32 .5 31. 6 29.8 28 .3
Q=Capacity
Three PhaseSing le Phase
Pump type Power
[kW] [ HP]
H= Tot al man ome tric he ad in met ers
