CENTRIFUGAL PUMPS CDX
SPECIFICATION 60Hz
200
EBARA PUMPS EUROPE S.p.A.
Rev. E
PUMP
Type of liquid Clean water
Liquid
Handled
Temperature [°C]
min. -5
max. +60 (CDX 70/076-70/106-70/156)
max. +90
max. +110 (H-HS-HW-HSW)
max. +120 (E)
Maximum working pressure [MPa] 0.8
Impeller Closed centrifugal type
Shaft seal type Mechanical seal
Construction
Bearing Sealed ball bearing
Suction [inch] from G 1¼ to G 1½ UNI ISO 228-1 Pipe
Connection
Discharge [inch] G 1 UNI ISO 228-1
Casing EN 1.4301 (AISI 304) - (AISI 316 only for “L” version)
Impeller EN 1.4301 (AISI 304) - (AISI 316 only for “L” version)
Casing cover EN 1.4301 (AISI 304) - (AISI 316 only for “L” version)
Shaft seal
Ceramic/Carbon/NBR (for CDX)
Ceramic/Carbon/FPM (for CDXH)
SiC/SiC/FPM (for CDXHS)
Tungsten Carbide/Tungsten Carbide/FPM (for CDXHW)
SiC/Tungsten Carbide/FPM (for CDXHSW)
Shaft AISI 303 / AISI 316 (Wet extension)
Material
Bracket Aluminium
Applicable standard of test ISO 9906 – Annex A
MOTOR
Electric - TEFC
Type
Single Phase Three Phase
No. of Poles 2
Rotation speed [min
-1
] ≈ 3450
Insulation Class F
Protection degree (CEI EN 60034-5) IP 55
[kW] 0.55 ÷ 1.5 0.55 ÷ 2.2
Power rating
[HP] 0.75 ÷ 2.0 0.75 ÷ 3.0
Frequency [Hz] 60
Voltage [V]
110-115 ±6%
220-230 ±6%
220/380-460 -6% +10%
Capacitor Built in -
Over load protection Built in Provided by the user
Casing material Aluminium
Base material / Motor support Aluminium
Dimensions of cable entry PG 11 - PG 13.5 (see dimensions page 400)
