2.2 Dimensions
24,7 ±0,5
66
126
106
115
2.3 Technical data
Designation Unit Value
Operating voltage [ V ] 9 … 32
Maximum input voltage [ V ] 32
Closed-circuit power consumption [ A ] <0.005
Current input in operation (GSM network) [ A ] <0.5
Maximum continuous current input, in operation [ mA ] <30
Operating temperature range [ °C ] –40 … +85
Storage temperature range [ °C ] –40 … +85
Dimensions, with fastening tabs L×W×H [ mm ] 126×66×25
Class of protection ISO 20653 IP40
Weight [ g ] 90
GSM / GPRS [ MHz ] Quad band: 850 / 900 / 1800 / 1900
Transmission power [ W ] 2 [33 dBm], Class 4 (GSM 850 / 900 MHz)
1 [30 dBm], Class 1 (GSM 1800 / 1900MHz)
6 22.1000.34.5106.0D EN | 06.2019
Operating instructions | EasyStart Web
