2 GTC116TRANSMITTERINTERIORVIEW/FEATURES






















Figure2.GTC116TransmitterInteriorView/Features
Outputsignalterminals
(Note:Theoutputfunction
isdependentonwhich
networkcardisinstalled)



LCDcontrast

TransmitterstatusLED
(Green1secondflashnormal;
2secondflashforfault)



Highaccuracy
A/Dconverter

Goldplatedinterconnects
tooptionaloutputcards

Positivelockingcable
receptacleswithgold
interconnects
Powerswitch

Switchingpowersupply
conservesenergyand
reducesheat

Pushbuttoninterface
simplifiesfieldconfiguration
(Note:devicesareplugandplayand
generallydonotrequireconfiguration.)

Expansionport


Multiplexersindependently
measuresensorvoltages
from1upto16sensingpoints


Goldplatedinterconnectsto
sensorinputreceptacles
