3.3 ConnectingSensorProbestotheTransmitter
Afterinstallingthesensorprobesandtransmitter,connecteachofthesensorprobecableplugstothecircular
receptacleslocatedatthebottomoftheGTC116transmitterenclosure.Probesare“PlugandPlay”anddonot
havetobeconnectedtoaspecificreceptacleonthetransmitterunlesstraversedatais
desired(seenotebelow).
TransmittersacceptonlyGP1andGB1sensors.
Providea“driploop”atthetransmitter if there willbethepotentialfor water runoffor
condensationalongthesensorprobecable(s).

Sensorprobecableplugsare“keyed”asshownbelow.Lineupplugwithreceptacleandpush
straightontoreceptacle.
DONOTTWIST. Squeezecableplug“ribs”towardsreceptaclewhenremoving.Forcingthecable
pluginoroutofthereceptaclewilldamagetheconnectorsandvoidwarranty.
Whentraversedata
isdesired(especiallywhenusingtheEB‐LinkReader),probesshouldbe
installedandconnectedtothetransmitterusingthemountingconventionspecifiedinthe
separateGP1/GB1sensorprobeInstallationGuide.Properinstallationsimplifiessensorlocation
decodingduringdataanalysis.










 



Figure4.TypeAandTypeBTransmitterConnectorPanelDetail
Figure 5.ConnectorDetail
TypeBTRANSMITTER
Accepts1to4probesupto4sensorseach
Squeezeandthenpulltoremove
DONOTTWIST!
TypeATRANSMITTER
Accepts1or2probesupto8sensorseach
!
!
!
!
