Ebyte E90-DTU User Manual

Chengdu Ebyte Electronic Technology Co.,Ltd. E90-DTU(xxxSLxx-ETH)_V2.0 User Manual
Copyright ©2012–2023，Chengdu Ebyte Electronic Technology Co.,Ltd.
5
PC
E90-DTU(xxxSLxx-ETH)_V2.0
E90-DTU(xxxSLxx)
RJ45 cable
DC12V-1A Power supply*2
Serial cable
TX433-JKD-20P*2
2.2 Software Preparation
Download the network debugging assistant "NetAssist" and serial port assistant "XCOM" from the product details
on Ebyte website, as shown below. Official website address: https://www.cdebyte.com.
Download the configuration tool for the corresponding product details, use "Ebyte Config Tool" for "Gateway Radio
E90-DTU( xxxSLxx-ETH)_V2.0" and use corresponding configuration software (e.g. "RF_Setting(E90-DTU SL)" ) for
"Serial Radio E9x-DTU(xxxSLxx)".
