Chengdu Ebyte Electronic Technology Co., Ltd. NB114 User Manual
Copyright ©2012–2023，Chengdu Ebyte Electronic Technology Co., Ltd.
2. Quick Start
If there is a problem in the use process, click the official website
link:https://www.ebyte.com/product-class.aspx
2.1. Preparation for use
Before using the serial server (hereinafter referred to as the "device"), it is necessary to
prepare the network cable, computer, USB to serial converter and other relevant auxiliary
materials. The details are as follows:
DC 12V switch power
supply
[Note] This case uses RS485 interface for demonstration;
2.2. Equipment wiring
Power wiring (DC 8~28V):
To Next Page
