ENGLISH
PLEASE NOTE: MINI TANKS ARE FOR INDOOR PERMANENT INSTALLATIONS ONLY. BEFORE POWERING THE WATER HEATER, BE SURE THAT THE SYSTEM IS COMPLETELY FILLED WITH WATER
AND ALL AIR IS REMOVED. THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE. PLEASE VISIT SUPPORT.ECCOTEMP.COM FOR MORE INFORMATION.
12
Support: Support.Eccotemp.com Shop Online: www.Eccotemp.com Phone: 866-356-1992
Installation Instructions
TEMPERATURE & PRESSURE RELIEF VALVE
Installaing the T&P Valve Discharge Pipe:
1. Must NOT be smaller in diameter than the outlet diameter of the valve, or have
any reducing couplings.
2. Must NOT be plugged or blocked.
3. Must be made of suitable material for hot water.
4. Must not be over 15 inches in length.
5. Must not have more than two elbows.
6. Must terminate at an adequate drain.
7. Must not have a shut o valve between relief valve and tank or relief valve and
termination of discharge.
A discharge line should be installed and exit only 6 inches above, or at any
distance below, and should not come in contact with any live electrical part.
The T&P discharge opening must not be blocked or reduced in size under any
circumstances.
IMPORTANT: Failure to provide dielectric insulation may result in
premature tank or nipple failure and may void your warranty. The T&P valve
is for servicing and the valve should be in the open position when the water
heater is in operation. DO NOT APPLY HEAT DIRECTLY TO INLET OR OUTLET
CONNECTIONS.
No more than 15 inches
combined length.
No more than 2
elbows.
Installed
(T&P Valve)
To Next Page
