36
EN
4) Installation
1. Move the device with the installed hot air exhaust tube kit in front of the window while maintaining
adistance of at least 50 cm from the walls or other objects. (Fig. 7).
50 cm
50 cm
Fig. 7
2. Place the short connector at end on the exhaust tube onto the oval opening of the window sealing insert
kit ( g. 8 and 9).
Note: The short connector at end on the hot air exhaust tube must fall into place. The exhaust tube must not
be folded and must not be markedly bent (more than 45°). The exhaust tube must properly ventilate.
Fig. 8 Fig. 9
