23. Remote controller
24. Round connector
25. Hot air exhaust tube
26. Short connector of the hot air exhaust tube
27. Window sealing insert kit
Fig. 12
Accessories:
Exhaust tube
Remote controller
Batteries – 2 pcs
Drain tube – 1 pc
Window installation kit – 1 pc
CONTROL PANEL
POWER
MODE
FAN
TIMER
°
F
Hr
C
°
Timer button
Two-digit
indicator
Celsius
indicator
Time
indicator
Fahrenheit
indicator
ON/OFF button
Fan button
Operating mode
select button
Up button
Down button
Cooling
indicator
Dehumidi cation
indicator
Fan
indicator
Timer
indicator
Sleep mode
indicator
High fan speed
indicator
Remote
controller
sensor
Water full
indicator
Low fan speed
indicator
Fig. 13
