Fig. 11
1. Control panel
2. Horizontal screen
3. Vertical screen
4. Air outlet
5. Vertical screen x lever
6. Wheel
7. Horizontal screen x lever
8. Main vertical screen
9. Front cover
10. Handle position (right side: remote controller
compartment)
11. Back cover
12. “C” clip for securing the hot air exhaust tube
13. Power cable
14. Bottom of the lower air inlet
15. Cable reel holder
16. Drain lid
17. Evaporator ltration screens
18. Evaporator lter frame
19. Fine radiation screens
20. Cooler ltration screens
21. Cooler lter frame
22. Base
