Echelon STRIDE - SECURING FOLDED TREADMILL; SAFETY STRAP INSTALLATION FOR STORAGE

22
|
FOLDING  STORAGE
When storing the treadmill in an upright position, please install
safety straps to the wall to secure and prevent treadmill from
tipping over.
Use the provided anchors and screws to install the safety straps. For
concrete walls, drill two 0.315in (8mm) pilot holes with 1.6in (40mm)
depth, 32in (81 cm) apart, and 47.2in (120cm) above floor. NOTE: For
wood walls, locate two wall studs 32in (81cm) apart and drill appropriate
pilot holes. Drive screws into pilot holes without anchors.
FOLDING  STORAGE (cont’d.)
32 IN (81 CM)
WIDTH APART
47.2 IN (120 CM)
ABOVE FLOOR
Safety Straps.
a. Safety straps, anchors, & screws
b. Safety strap position
11
STEP
11-a 11-b
