Counter Top Installation Instructions
Connecting to a Standard Faucet
Connecting to a Cold
Water Valve
Warning! Make sure the arrow on the
dust pre-lter is pointing
the same direction as the
water ow.
Warning!
Make sure the arrow on the
dust pre-lter is pointing
the same direction as the
water ow.
Dust Pre-Filter
Source water
Source water
Dust Pre Filter
diverter
valve
Cold Water Valve
outlet
inlet
inlet
T-Adapter
inlet
outlet
