Echo CS-2511T Owner's/Operator's Manual

18
CS-2511T
WHEN THE ENGINE IS COLD
CAUTION
Make sure the bar and chain are free from
any obstruction when starting the chain saw.
• Move chain brake lever fully forward to lock
chain brake before starting.
• Fill the fuel tank with fuel mixture.
It is not permitted to ll fuel above the shoulder
level of fuel tank.
• Fill the chain oil tank with lubricant.
Do not over ll.
• Move ignition switch to “Run” position.
• Push purge pump 3 to 4 times or until fuel is
visible in purge pump.
• Turn choke control knob counterclockwise.
(Choke position )
• Securely hold the chain saw as shown.
When starting the chain saw place the unit on
a at ground and hold the front handle with left
hand and hold rmly the rear end of rear handle
with right knee and pull starter handle with right
hand several times until rst ring sound.
• Turn choke control knob clockwise.
(Open position )
• Pull starter handle to start the engine.
• When engine starts, immediately squeeze and
release throttle trigger to release fast idle throttle
latch otherwise severe brake damage may occur.
WHEN THE ENGINE IS WARM
CAUTION
Make sure the bar and chain are free from
any obstruction when starting the chain saw.
• Move chain brake lever fully forward to lock
chain brake before starting.
• Conrm there is fuel and chain oil in the tanks.
• Move ignition switch to “Run” position.
• Securely hold the chain saw as shown and pull
starter handle.
• Choke may be used if necessary, but after rst
ring sound, squeeze and release throttle trigger
to release fast idle throttle latch otherwise severe
brake damage may occur.
Open choke
Choke control knob
Start / Run
Ignition switch
Chain brake
Starter handle
Purge pump
Choke
Choke control knob
Chain brake
